Overview

The exhaust gas is powered by the fan, and the negative pressure enters the activated carbon adsorption layer after entering the adsorption box. Because there is an unbalanced and unsaturated molecular gravity or chemical bond on the surface of the activated carbon adsorbent, when the surface of the activated carbon adsorbent is in contact with the gas, the gas molecules can be attracted to make it concentrated and remain on the surface of the activated carbon, this phenomenon is called adsorption. The adsorption capacity of the surface of activated carbon adsorbent is used to make the exhaust gas contact with the porous activated carbon adsorbent on the large surface, and the pollutants in the exhaust gas are adsorbed on the surface of the activated carbon, so that it is separated from the gas mixture, and the purified gas is discharged at high altitude.

Technical features

1. High adsorption efficiency and strong capacity

2. Can handle a variety of mixed organic waste gas at the same time, purification efficiency ≥95%

3. Compact structure and small footprint

4. Simple maintenance and management, low operating cost

5. Fully closed type, indoor and outdoor can be used

Application field

1. Activated carbon adsorption box is mainly used for large air volume and low concentration of organic waste gas treatment;

2. Activated carbon adsorbent can treat and purify a variety of organic and inorganic pollutants: benzene, ketone, ether, alkane and their mixed organic waste gas, acid waste gas, alkaline waste gas;

3. Mainly used in pharmaceutical, smelting, chemical, machinery, electronics, electrical appliances, painting, shoemaking, rubber, plastics, printing, environmental protection desulfurization, deodorization and various industrial production workshops of harmful waste gas purification treatment.

4. And a wide range of treatment objects, the "National odor Pollution control Standard" stipulated in the eight odor substances hydrogen sulfide, ammonia, trimethylamine, methylmertan, methyl sulfide, carbon disulfide, styrene, dimethyl disulfide can be effectively removed, and the following substances can be effectively decomposed and purified.

Technical characteristics
